RECYCLING AND DISPOSAL
74
APPENDIX
APPENDIX
Menu
Par.
No.
Nr. dis-
played
Display
Description Range
Default
setting
UM
Access
type
Category
M1 124
Prog.
Input
RT.
The value of this parameter is dened by Par. 97.
0 Disabled
1 Enabled
Dened
by Par. 97
I General
M1 125
Prog.
Output 1.
The value of this parameter is dened by Par. 97.
0 Disabled
1 General Pump
2 CH Pump
3 DHW Pump
4 System Pump
5 Cascade Pump
6 Alarm Relay
7 Filling Valve
8 LPG Tank
9 External
Igniter
10 Air Damper
14 Alarm Burner
CC
15 Status Burner
CC
17 Anti-legio-
nella pump
Dened
by Par. 97
I General
M1 126
Prog.
Output
2.
The value of this parameter is dened by Par. 97.
0 Disabled
1 General Pump
2 CH Pump
3 DHW Pump
4 System Pump
5 Cascade Pump
6 Alarm Relay
7 Filling Valve
8 LPG Tank
9 External
Igniter
10 Air Damper
14 Alarm Burner
CC
15 Status Burner
CC
17 Anti-legio-
nella pump
Dened
by Par. 97
I General
M1 127
Prog.
Output
3.
The value of this parameter is dened by Par. 97.
0 Disabled
1 General Pump
10 Air Damper
11 HIS
12 Modulating
Pump
Dened
by Par. 97
I General
M1 128
Prog.
Output
4.
The value of this parameter is dened by Par. 97.
0 Disabled
1 General Pump
2 CH Pump
3 DHW Pump
4 System Pump
5 Cascade Pump
6 Alarm Relay
7 Filling Valve
8 LPG Tank
Dened
by Par. 97
I General
M1 129
Flow
sensor
Denes the type of supply sensor used.
Bitron, Huba:
DN8, DN10,
DN15, DN15,
DN20, DN25
Huba
DN25
I General
M1 138
Appli-
ance
type
Value can vary depending on appliance congura-
tion based on Par. 97 and 98. This value is calculat-
ed by the board, which, based on an internal logic,
denes as a single number the settings of Par. 97
and 98.
0 - 255
Depends
on boiler
model
I General
