Riello G200 - PROPANE BURNER SETTINGS

3254
17
GB
SETTING UP THE BURNER
After burner output has been determined, use TABLE below AS AN INITIAL GUIDE
for burner settings.
All settings in this table were obtained under the following conditions.
O
0 (zero) draft in the combustion zone;
O
Standard lab test boiler;
O
Inlet gas pressure range as in table;
O
Steady state (HOT) operating conditions.
Gas inlet
pressure range
Orifice
Manifold
gas pressure
Burner
output
Head
setting
Air gate
setting
“wc Marking “wc Btu/hr Nocth Notch
PROPANE
12.0 - 14.0
B11
3.5
75,000 0 1.5
B12 91,529 0 1.8
B13 108,341 1 1.5
B14 129,822 2 2
B15 158,776 3 2.25
B16 200,000 4 3.5
