UPS Models 10 kVA 12 kVA 15 kVA 20 kVA
Dimensions and weight
W x D x H
MCT 320 x 840 x 930 mm
MST 440 x 850 x 1320 mm
Weight without batteries
MCT 80 Kg 82 Kg 90 Kg 95 Kg
MST 105 Kg 110 Kg 115 Kg 120 Kg
Weight with batteries
MCT 180 Kg 182 Kg 190 Kg 195 Kg
MST 305 Kg 310 Kg 315 Kg 320 Kg
Modes and efficiency values
Operating modes
True on line double conversion
ECO mode
Smart Active mode
Stand-by Off (Emergency)
Frequency Converter
AC/AC efficiency in on line mode
≥93.5% ≥94%
AC/AC efficiency in Eco mode
≥98%
DC/AC efficiency in autonomy mode ≥92.5% ≥93.5%
Miscellaneous
Noise ≤48dB(A) ≤52dB(A)
Color RAL 7016
Ambient temperature
0 – 40 °C
(1)
To maintain the output voltage within the range of precision indicated, it may have to be recalibrated after a long period of operation
(2)
If the mains frequency is within ± 5% of the selected value, the UPS is synchronized with the mains. If the frequency is outside the
tolerance limits or running on the battery, the frequency is the value selected +0.1%
(3)
Mains/Battery @ load 0% -100%
(4)
@ Mains / battery / mains @ resistive load 0% / 100% / 0%
(5)
The recharging current is regulated automatically according to the capacity of the battery installed
(6)
20 – 25 °C for maximum battery life
(7)
@ 100% load & THDv ≤ 1%
Battery Box
BBX 1320 480V
BB NP T4 3F
BBX 1320 480V
BB NP T2 3F
BBX 1320 480V
BB NP T8 3F
BBX 1320 480V
BB NP T5 3F
Battery
Rated voltage per branch 240 Vdc
No. batteries / V / Ah 80 / 12 / 9 120 / 12 / 7 80 / 12 / 12 120 / 12 / 9
Miscellaneous
Ambient temperature
(1)
0 – 40 °C
Humidity <95% non-condensing
Protective devices Overcurrent – Short circuit
W x D x H 400 x 815 x 1320 mm
Weight 300 Kg 390 Kg 395 Kg 400 Kg
(1)
20 – 25 °C for maximum battery life
