V IEW OF THE UPS C ONNECTIONS
Connection for the R.E.P.O command (Remote Emergency Power Off)
(see previous page for the MST version)
Power connections: BATTERY, INPUT, SEPARATE BYPASS (optional), OUTPUT
Connection for remote maintenance bypass command
Connection for external Battery Box temperature probe
Connection for external synchronization signal
Slot for power relay board
