Rigol DG1032Z Calibration Guide

RIGOL Chapter 1 Calibration Notices
1-2 DG1000Z Calibration Guide
To Acquire the Calibration Service
Improper calibration may result in output accuracy reduction and even output error.
RIGOL does not recommend manual calibration by users. If calibration is required,
please contact RIGOL customer service department or the local distributor.
Recommended Test Devices
It is recommended that you use the test devices listed in the table below or other test
devices whose performance specifications satisfy the “Performance Requirement”
listed in the table below for calibration.
Table 1-1 Recommended Test Devices
Device
Performance Requirement
Recommended
Digital Multimeter
6
1
/
2
digits
RIGOL DM3068
Frequency Counter
>10MHz
Accuracy: 0.1ppm
Agilent 53131A
Power Meter
-30dBm to +20dBm
Accuracy: ±0.02dB
Resolution: 0.01dB
Agilent E4418B
Connecting Wire
BNC (m) - Dual banana plug (m)
--
Connecting Wire
BNC (m) - BNC (m)
--
Power Sensor -30dBm to +20dBm Agilent N8482A
Power Sensor
Connecting Wire
Used to connect the power meter and
power sensor
--
50Ω Load 50Ω/1W --
Test Notices
For optimum performance, all procedures should comply with the following
recommendations.
1) Make sure the environment temperature is stable and between 18℃ and 28℃.
Ideally, the calibration should be performed at 23℃±1℃.
2) Make sure the environment relative humidity is less than 80%.
3) Make sure that the instrument has been warmed up for at least 30 minutes
before the calibration.
4) Keep the test cables as short as possible and make sure that the impedance of
the cable is consistent with the requirement.
