Parameter
Name Type Range Default
<ohms> Integer 1 Ω to 10000 Ω 50 Ω
Explanation
Default setting: INFinity (HighZ)
This command is completely compatible with the following commands.
:OUTPut[<n>]:IMPedance <ohms>|INFinity|MINimum|MAXimum
:OUTPut[<n>]:IMPedance? [MINimum|MAXimum]
Return Format
The query returns the specific impedance value or INFINITY (HighZ).
Example
The command below sets the output impedance of the [Output2] connector to 100 Ω.
:OUTPut2:LOAD 100
The query below returns 100.
:OUTPut2:LOAD?
Related Commands
:OUTPut[<n>]:IMPedance <ohms>|INFinity|MINimum|MAXimum
:OUTPut[<n>]:IMPedance? [MINimum|MAXimum]
