Parameter
Name Type Range Default
<depth> Consecutive Real Number 0% to 120% 100%
Explanation
The range of <depth> is from 0% to 120% and setting without % is supported.
In 0% modulation, the output amplitude is half of the specified value.
In 100% modulation, the output amplitude is equal to the specified value.
In >100% modulation, the output amplitude of the instrument would not exceed 10 Vpp
(50 Ω load).
Return Format
The query returns the modulation depth in scientific notation.
Example
The command below sets the modulation depth to 80%.
:MOD:AM 80
The query below returns 8.000000E+01.
:MOD:AM?
