Chapter 3 Remote Control RIGOL
DP800 User’s Guide 3-9
resource name to select it and then click .
If resource cannot be found automatically:
Select the GPIB card address of the PC from the dropdown box of "GPIB0::"
and select the GPIB address set in the power supply from the dropdown box
of "0::INSTR".
Click
to check whether the GPIB communication works
normally; if not, please follow the corresponding prompt messages to solve
the problem.
5. View the device resource
The resource found will appear under the "RIGOL Online Resource" directory as
shown in the figure below.
6. Control the instrument remotely
Right-click the resource name "DP832 (GPIB0::18::INSTR)" and select "SCPI
Panel Control" to turn on the remote command control panel through which you
can send commands and read data.
