RIGOL Chapter 2 Front Panel Operations
2-54 DP800 User’s Guide
VISA descriptor is the resource name and describes the accurate name and
location of the VISA resource. If the LAN interface is currently used to
communicate with the instrument, the VISA descriptor is
TCPIP::172.16.3.100::INSTR.
5. Set the IP Address
Please acquire a valid IP address from your network administrator firstly and set
the IP address manually in manual IP configuration mode. The format of the IP
address is nnn.nnn.nnn.nnn; wherein, the first nnn ranges from 1 to 223
(except 127) and the other three range from 0 to 255.
Press IP Addr and use the numeric keyboard and left/right direction key or the
knob and left/right direction key to input the desired IP address. This setting is
stored in the non-volatile memory and the instrument will load the IP address
set automatically at the next power-on if DHCP and Auto IP are set to "Off".
6. Set the Subnet Mask
Please acquire a valid subnet mask from your network administrator firstly and
set the subnet mask manually in manual IP configuration mode. The format of
the subnet mask is nnn.nnn.nnn.nnn; wherein, the range of nnn is from 0 to
255.
Press Sub Mask and use the numeric keyboard and left/right direction key or
the knob and left/right direction key to input the desired subnet mask. This
setting is stored in the non-volatile memory and the instrument will load the
subnet mask set automatically at the next power-on if DHCP and Auto IP are
set to "Off".
7. Set the Gateway
Please acquire a valid gateway address from your network administrator firstly
and set the gateway manually in manual IP configuration mode. The format of
the gateway is nnn.nnn.nnn.nnn; wherein, the first nnn ranges from 1 to 223
(except 127) and the other three range from 0 to 255.
Press Gateway and use the numeric keyboard and left/right direction key or the
knob and left/right direction key to input the desired gateway address. This
setting is stored in the non-volatile memory and the instrument will load the
gateway address set automatically at the next power-on if DHCP and Auto IP
are set to "Off".
8. Set the DNS Server
Please acquire a valid DNS server address from your network administrator
firstly and set the DNS (Domain Name Service) address manually in manual IP
configuration mode. The format of the DNS address is nnn.nnn.nnn.nnn;
wherein, the first nnn ranges from 1 to 223 (except 127) and the other three
range from 0 to 255.
