Chapter 2 Front Panel Operations RIGOL
DP800 User’s Guide 2-57
To Set the GPIB Address
Before using the GPIB interface, use the USB to GPIB interface converter (option) to
extend a GPIB interface and then use a GPIB cable to connect the instrument and
PC.
Press Utility  I/O Config  GPIB and use the numeric keyboard or the left/right
direction key and knob to set the desired GPIB address. It can be any integer from 0
to 30. The default is 2. This setting is stored in the non-volatile memory and will not
be affected by factory reset.
System Setting
Power-on Setting
Select the instrument configuration ("Default" or "Last") the instrument uses at
power-on and the default is "Default".
 Last: use the system configuration before the last power-off.
 Default: use the factory setting (except those parameters that are not affected
by factory reset). For the details, refer to
 Table 2-2.
Press Utility  System  Power On to select the desired configuration type. This
setting is stored in the non-volatile memory and will not be affected by factory reset.
Over-temperature Protection
Press Utility  System  OTP to enable or disable the over-temperature
protection (OTP) function. When the OTP function is enabled, the instrument turns
off the output automatically when the temperature inside the instrument reaches the
limit.
Beeper
Press Utility  System  Beeper to enable or disable the beeper. When the
beeper is enabled, the instrument generates prompt sound during front panel
operation or when error occurs during remote operation.
