RIGOL Chapter 2 Front Panel Operations
2-62 DP800 User’s Guide
Table 2-2 Factory setting
Channel Parameters
DP832
Voltage/Current Setting
Values
CH1: 00.00V/3.000A
CH2: 00.00V/3.000A
CH3: 0.00V/3.000A
Voltage/Current Limits
CH1: 33.00V/3.300A
CH2: 33.00V/3.300A
CH3: 5.50V/3.300A
OVP/OCP On/Off CH1/CH2/CH3: Off/Off
Output On/Off CH1/CH2/CH3: Off
Track On/Off
CH1/CH2: Off
CH3: None
Current Channel CH1
DP831
Voltage/Current Setting
Values
CH1: 0.000V/5.000A
CH2: 00.00V/2.000A
CH3: -00.00V/2.000A
Voltage/Current Limits
CH1: 8.800V/5.500A
CH2: 33.00V/2.200A
CH3: -33.00V/2.200A
OVP/OCP On/Off CH1/CH2/CH3: Off/Off
Output On/Off CH1/CH2/CH3: Off
Track On/Off
CH1: None
CH2/CH3: Off
Current Channel CH1
DP821
Voltage/Current Setting
Values
CH1: 00.00V/1.000A
CH2: 0.00V/10.00A
Voltage/Current Limits
CH1: 66.00V/1.100A
CH2: 8.80V/11.00A
OVP/OCP On/Off CH1/CH2: Off/Off
Output On/Off CH1/CH2: Off
Sense Function On/Off
CH1: None
CH2: Off
Current Channel CH1
DP811
Voltage/Current Setting
Values
00.00V/05.00A
Voltage/Current Limits 22.00V/11.00A
OVP/OCP On/Off Off/Off
Output On/Off Off
Sense Function On/Off Off
Current Range Range1
