Rigol DP832 Performance Verification Manual

Chapter 1 Test Overview RIGOL
DP800 Performance Verification Manual
1-5
Recommended Test Devices
It is recommended that you use the test devices listed in the table below or other test
devices whose performance specifications satisfy the “Performance Requirement”
listed in the table below to test the performance specifications of the DP800 series.
Table 1-2 Recommended Test Devices
Device Performance Requirement
Recommended
Instrument
Use
Digital
Oscilloscope
Bandwidth: ≥20MHz
Minimum Vertical Scale: ≤2mV/div
Bandwidth Limit: ≤20MHz
RIGOL
DS1102E
Measure ripple and
noise, transient
response time
Digital
Multimeter
Readout Resolution: 6½
RIGOL DM3068
Measure dc voltage
RMS
Voltmeter
Sensitivity: 1mV
Bandwidth: ≥10MHz
Measure rms ripple
and noise
Electronic
Load
Voltage Range: 80Vdc
Current Range: 60Adc
Maximum Power: 300W
Dynamic frequency: 1kHz
Chroma 63103A
Measure load
regulation rate, linear
regulation rate,
transient response
time
AC Power
Supply
Regulation Rate: >1% Chroma 61602 __
Resistive
Load R
L
0.8Ω (200W)
1.6Ω (100W)
2Ω (400W)
8Ω (400W)
10Ω (200W)
15Ω (200W)
60Ω (200W)
__
Measure ripple and
noise
Current
Sampling
Resistor R
M
0.022Ω
(5W, temperature drift: 10ppm)
__
Measure load
regulation rate, linear
regulation rate,
programming
accuracy and
readback accuracy
Multimeter
Test Probe
__ __ __
USB Cable
USB Device to USB Host, for
connecting the power supply and PC
__ __
Short Circuit
Device (2)
__ __
Short-circuit the (S+)
and (+) terminals,
(S-) and (-) terminals
of the channel that
supports the Sense
function

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
