Rigol DP832 Performance Verification Manual

Appendix RIGOL
DP800 Performance Verification Manual
9
DP832 Performance Verification Test Record Form
RIGOL DP832 Programmable Linear DC Power Supply
Performance Verification Test Record Form
CV Load Regulation Rate
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <5mV <5mV <2.5mV
DP832
Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Measurement
Result
U
0
U
1
|U
1
-U
0
|
CV Linear Regulation Rate
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <5mV <5mV <2.5mV
DP832
Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Measurement
Result
U
0
U
1
U
2
|U
1
-U
0
|
|U
2
-U
0
|
CV Ripple and Noise
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <350μVrms/3mVpp
Resistive Load R
L
10Ω 10Ω 1.6Ω
DP832 Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Measurement
Result
Peak-peak value
(Vpp)
RMS value
(Vrms)

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
