Chapter 2 Constant Voltage Tests RIGOL
DP800 Performance Verification Manual
2-15
Table 2-15 DP821A CV Ripple and Noise Test Record Form
Channel CH1 (60V/1A) CH2 (8V/10A)
Specification <350μVrms/3mVpp
Resistive Load R
L
60Ω 0.8Ω
DP821A
Setting
Voltage 60V 8V
Current 1.05A 10.5A
Measurement
Result
Peak-peak value
(Vpp)
RMS value
(Vrms)
Table 2-16 DP811A CV Ripple and Noise Test Record Form
Range Range1 (20V/10A) Range2 (40V/5A)
Specification <350μVrms/3mVpp
Resistive Load R
L
2Ω 8Ω
DP811A
Setting
Voltage 20V 40V
Current 10.5A 5.3A
Measurement
Result
Peak-peak value
(Vpp)
RMS value
(Vrms)

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
