Rigol DP832 Performance Verification Manual

Chapter 3 Constant Current Tests RIGOL
DP800 Performance Verification Manual
3-13
Table 3-12 DP832A CC Ripple and Noise Test Record Form
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <2mArms
Resistive Load R
L
10Ω 10Ω 1.6Ω
DP832A
Setting
Voltage 32V 32V 5.3V
Current 3A 3A 3A
Measurement
Result
RMS value
(Vrms)
Vrms/R
L
Table 3-13 DP832 CC Ripple and Noise Test Record Form
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <2mArms
Resistive Load R
L
10Ω 10Ω 1.6Ω
DP832 Setting
Voltage 32V 32V 5.3V
Current 3A 3A 3A
Measurement
Result
RMS value
(Vrms)
Vrms/R
L
Table 3-14 DP821A CC Ripple and Noise Test Record Form
Channel CH1 (60V/1A) CH2 (8V/10A)
Specification <2mArms
Resistive Load R
L
60Ω 0.8Ω
DP821A
Setting
Voltage 63V 8.4V
Current 1A 10A
Measurement
Result
RMS value
(Vrms)
Vrms/R
L
Table 3-15 DP811A CC Ripple and Noise Test Record Form
Range Range1 (20V/10A) Range2 (40V/5A)
Specification <2mArms
Resistive Load R
L
2Ω 8Ω
DP811A
Setting
Voltage 21V 42V
Current 10A 5A
Measurement
Result
RMS value
(Vrms)
Vrms/R
L

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
