DP832 Performance Verification Test Record Form
RIGOL DP832 Programmable Linear DC Power Supply
Performance Verification Test Record Form
CV Load Regulation Rate
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <5mV <5mV <2.5mV
DP832
Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Measurement
Result
U
0
U
1
|U
1
-U
0
|
CV Linear Regulation Rate
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <5mV <5mV <2.5mV
DP832
Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Measurement
Result
U
0
U
1
U
2
|U
1
-U
0
|
|U
2
-U
0
|
CV Ripple and Noise
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <350μVrms/3mVpp
Resistive Load R
L
10Ω 10Ω 1.6Ω
DP832 Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Measurement
Result
Peak-peak value
(Vpp)
RMS value
(Vrms)
