DP800 Performance Verification Manual
VI
Document Overview
DP800 series is a high-performance programmable DC power supply. This manual
introduces the performance verification test methods of DP800 series. The
performance verification test mainly verifies whether DP800 series programmable
linear DC power supply can work normally and is within specifications.
Main topics of this manual
Chapter 1 Test Overview
This chapter introduces the test preparations, the recommended test devices, the
test precautions as well as the test result record and so on.
Chapter 2 Constant Voltage Tests
This chapter introduces the specification test methods of DP800 under constant
voltage (CV) mode.
Chapter 3 Constant Current Tests
This chapter introduces the specification test methods of DP800 under constant
current (CC) mode.
Appendix
Provide the test result record forms and the performance specifications of all models
of DP800 series programmable linear DC power supply.
Content Conventions in this Manual
DP800 series programmable linear DC power supply includes the following models.
Unless specified otherwise in this manual, DP831A is taken as an example to
illustrate the performance verification test methods of DP800 series.
Model Channel Output Voltage/Current
DP831A 3 8V/5A, 30V/2A, -30V/2A
DP832A/DP832 3 30V/3A, 30V/3A, 5V/3A
DP821A 2 60V/1A, 8V/10A
DP811A 1 20V/10A (Range 1), 40V/5A (Range 2)
