Table 2-86 The Cursor menu
Cursor Increment Operation
Cursor A
X
Y
Turn the multifunctional knob (
) to move
cursor A horizontally.
Turn the multifunctional knob (
) to move
cursor A vertically.
Cursor B
X
Y
Turn the multifunctional knob (
) to move
cursor B horizontally.
Turn the multifunctional knob (
) to move
cursor B vertically.
NOTE: Cursor could be moved only when the curse function menu is displayed.
5. To get measurement values:
Position of Cursor A: Time cursor centered on the midpoint of screen; Voltage
cursor centered on channel ground level.
Position of Cursor B: Same as above.
Horizontal space between cursor A and B (
△X): Time between cursors (1/△X),
units in Hz, kHz, MHz, and GHz.
Vertical space between cursor A and B (
△Y): Voltage between cursors.
NOTE: The values will be automatically displayed on the right upper corner of
screen when the cursor function menu is hidden or displaying other menus.
Term Explanations
Cursor Y: Cursors Y appear as horizontal lines on the display to measure
vertical parameters. Usually it is used to measure the Volts. When the
source is set as function, the units are assigned to the function.
Cursor X: Cursor X appears as vertical lines on the display to measure
horizontal parameters. Usually it indicates the time of trigger excursion.
When the source is set as FFT, X means frequency.
