To Display a Signal Automatically
The oscilloscope has an automated feature to display the input signal in best-fit
status. The input signal should be 50 Hz or higher and a duty cycle is greater than
1%.
Using the automatic setting:
1. Connect a signal to the oscilloscope (such as channel 1) as described above.
2. Press Auto.
The oscilloscope may change the current settings to display the signal; adjusts the
vertical and horizontal scaling, the trigger coupling, type, position, level, and mode.
