Rigol DS1000B Series User Manual

RIGOL
User’s Guide for DS1000B series
2-108
Auto-Set functions
When the Auto is pressed the oscilloscope is configured to the following defaults:
Table 2-91 The Auto menu
Menu Settings
Display format Y-T
Acquire mode Normal
Vertical Position Adjusted to right position
Vertical “V/div” Adjusted to right scale
Volts/Div Coarse
Bandwidth limit Full
[1]
Signal Invert OFF
Horizontal position Center
Horizontal “S/div” Adjust to right position.
Trigger type Edge
Trigger source Find the channel with input signal automatically.
Trigger coupling DC
Trigger voltage Midpoint setting
Trigger mode Auto
NOTE:
[1] The Bandwidth limit will turn on automatically as soon as measuring small signal.
Run/Stop: Run or Stop waveform acquiring.
NOTE: In Stop status, the volts/div and horizontal time base can be adjusted in a
fixed limit. That is, to zoom in/out the signal in vertical and horizontal directions.
Single: When running, press this key to stop the oscilloscope, when stopped, press
this key to make a single acquisition when the trigger occurs, then stop.
