3. The horizontal knob moves displayed signal horizontally on the
waveform window.
The horizontal
knob adjusts the trigger offset of signal, when
turning the knob; you can note that the waveform moves horizontally in
conjunction with the knob.
Horizontal offset back to 0 shortcut key
Rotate the horizontal
knob to adjust the horizontal position
of the signal in the waveform window and press it down to restore the
trigger offset or (delayed sweep offset) to the zero point.
