RIGOL
User’s Guide for DS1000B Series
2-15
Figure 2-17 Table 2-7 The Math menu (Page 2/2)
Menu Settings Comments
The multifunctional knob (
) adjusts
the vertical position of the Math
waveform.
The multifunctional knob ( ) adjusts
the vertical amplitude of the Math
waveform.
Reset
Reset the math waveform to vertical
mid-point.
