Rigol DS1052E Service Guide

RIGOL
Service Guide for DS1000E, DS1000D Series
VIII
Figures
Figure 2-1 Connect the power cord ................................................................... 2-3
Figure 2-2 Power-on inspection ........................................................................ 2-3
Figure 2-3 Connect probe to oscilloscope .......................................................... 2-4
Figure 2-4 Connect probe to circuit ................................................................... 2-4
Figure 2-5 Set the probe attenuation quotient and switch ................................... 2-5
Figure 2-6 Connect the probe compensator ....................................................... 2-5
Figure 2-7 Waveform compensation .................................................................. 2-6
Figure 2-8 Connect the digital probes to oscilloscope ......................................... 2-7
Figure 2-9 Test clip of digital probe ................................................................... 2-7
Figure 2-10 Attach the clip to testing point ........................................................ 2-8
Figure 2-11 Connect to the ground ................................................................... 2-8
Figure 3-1 Connect the U disk .......................................................................... 3-2
Figure 3-2 Successful prompt of USB interface connection .................................. 3-2
Figure 3-3 USB Device interface connection ....................................................... 3-4
Figure 3-4 Select USB interface ........................................................................ 3-4
Figure 3-5 Fail to connection ............................................................................ 3-5
Figure 3-6 RS-232 interface connection ............................................................. 3-6
Figure 3-7 Select RS-232 interface .................................................................... 3-6
Figure 3-8 RS-232 interface setting ................................................................... 3-7
Figure 3-9 Fail prompt of RS-232 interface connection ........................................ 3-7
Figure 3-10 P/F interface connection ................................................................. 3-8
Figure 3-11 DS1000D LA interface connection ................................................... 3-9
Figure 3-12 Setting interface .......................................................................... 3-10
Figure 3-13 Edge trigger of digital channel ...................................................... 3-10
Figure 4-1 Self-Calibration interface .................................................................. 4-1
Figure 4-2 Finish Self-Calibration ...................................................................... 4-1
Figure 5-1 Structure chart ................................................................................ 5-3
Figure 5-2 Disassemble and assemble the cover ................................................ 5-4
Figure 5-3 Disassemble and assemble the upper and rear covers ........................ 5-5
Figure 5-4 Disassemble and assemble the power board and the fan .................... 5-6
Figure 5-5 Disassemble and assemble the panel ................................................ 5-8
Figure 5-6 Disassemble and assemble LCD and the keyboard ............................. 5-9
Figure 5-7 Disassemble and assemble the mainboard ....................................... 5-10
Figure 7-1 DS1000E, DS1000D Exploded View ................................................... 7-1

Rigol DS1052E Specifications

General

Bandwidth	50 MHz
Sample Rate	1 GSa/s
Channels	2
Memory Depth	1 Mpts
Vertical Sensitivity	2 mV/div to 10 V/div
Input Impedance	1 MΩ ± 2% || 15 pF ± 3 pF
Vertical Resolution	8 bits
Trigger Modes	Edge, Pulse, Video, Slope, Alternate
Power Supply	100-240 V AC, 45-440 Hz
Display	5.7 inch TFT LCD
Interfaces	USB Host, USB Device, RS-232
Dimensions	303 mm x 154 mm x 133 mm
