Chapter 3 Performance Test RIGOL
Service Guide for DS1000E, DS1000D Series
3-7
4. Click Communication Setting and setup the communication interface under
using and the baud rate.
Figure 3-8 RS-232 interface setting
5. Press UtilityI/O Setting and set the baud rate as the same value in Ultrascope.
6. Click ToolsConnect to Oscilloscope; If successful, the corresponding
reminder light at the upper right corner of the software will be changed from red
to blue; otherwise, a prompting message will be appeared as below.
Figure 3-9 Fail prompt of RS-232 interface connection

Table of Contents

Other manuals for Rigol DS1052E

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Rigol DS1052E and is the answer not in the manual?

Rigol DS1052E Specifications

General IconGeneral
Bandwidth50 MHz
Sample Rate1 GSa/s
Channels2
Memory Depth1 Mpts
Vertical Sensitivity2 mV/div to 10 V/div
Input Impedance1 MΩ ± 2% || 15 pF ± 3 pF
Vertical Resolution8 bits
Trigger ModesEdge, Pulse, Video, Slope, Alternate
Power Supply100-240 V AC, 45-440 Hz
Display5.7 inch TFT LCD
InterfacesUSB Host, USB Device, RS-232
Dimensions303 mm x 154 mm x 133 mm
