Chapter 3 Performance Test RIGOL
Service Guide for DS1000E, DS1000D Series
3-3
3. If an update program about the oscilloscope available in the U disc is detected, a
prompt will appeared to ask you whether to update or not; if select OK, the
corresponding update process will be shown on the screen.
4. Press Storage→External to copy or delete the information in U disc.
5. Remove the U disc and a corresponding prompt “USB device removed” will
appear.

Rigol DS1052E Specifications

General

Bandwidth	50 MHz
Sample Rate	1 GSa/s
Channels	2
Memory Depth	1 Mpts
Vertical Sensitivity	2 mV/div to 10 V/div
Input Impedance	1 MΩ ± 2% || 15 pF ± 3 pF
Vertical Resolution	8 bits
Trigger Modes	Edge, Pulse, Video, Slope, Alternate
Power Supply	100-240 V AC, 45-440 Hz
Display	5.7 inch TFT LCD
Interfaces	USB Host, USB Device, RS-232
Dimensions	303 mm x 154 mm x 133 mm
