10 MSO1000Z/DS1000Z Quick Guide
The instrument can output a positive pulse via this connector when a failed
waveform is detected during the pass/fail test. The instrument continuously
outputs a low level via this connector when no failed waveform is detected.
5． Source Output
The output terminals of the built-in dual-channel source of the oscilloscope.
When Source1 or Source2 is enabled, the signal currently set can be output
through the [Source1] or [Source2] connector at the rear panel.
6． Lock Hole
You can lock the instrument to a fixed location using the security lock (please
buy it yourself) via the lock hole.
7． Fuse
If a new fuse is required, please use the specified fuse (250V, T2A). The
operation method is as follows:
a) Turn off the instrument, disconnect the power, and then remove the power
cord.
b) Insert a small straight screwdriver into the slot at the power socket and
prize out the fuse seat gently.
c) Take out the fuse and replace it with a specified fuse. Then, install the fuse
seat.
8． AC Power Socket
AC power input terminal. The power requirements of this oscilloscope are
100-240 V, 45-440 Hz. Use the power cord provided with the accessories to
connect the instrument to AC power. Then, you can press the power key at the
front panel to start the instrument.
To Next Page
