22 MSO1000Z/DS1000Z Quick Guide
To Use the Built-in Help System
The help system of this oscilloscope provides instructions for all the function keys
(including menu keys) at the front panel. Press Help to open the help interface and
press again to close the interface. The help interface mainly consists of two parts.
The left is “Help Options” and the right is “Help Display Area”.
Figure 15 Help Information
You can press the button (except the power key
, the knob and the menu
page up/down key
/ ) at the front panel directly to get the corresponding help
information in the “Help Display Area”.
Help Options Help Display Area
