Chapter 1 Quick Start RIGOL
MSO1000Z/DS1000Z User’s Guide 1-13
Logic Analyzer
Press this key to open the logic analyzer control menu. You can turn
on or off any channel or channel group, modify the display size of the
digital channel, modify the logic threshold of the digital channel as
well as group the 16 digital channels. You can also set a label for
each digital channel.
Note:
― This function is only applicable to MSO1000Z and DS1000Z Plus with the MSO
upgrade option.
― Press LA ïƒ D7-D0; when "On" is selected, CH4 function is automatically
disabled; when "Off" is selected, CH4 function recovers automatically. Press LA
ïƒ D15-D8; when "On" is selected, CH3 function is automatically disabled;
when "Off" is selected, CH3 function recovers automatically.
Signal Source
Press this key to enter the source setting interface. You can enable or
disable the output of the [Source 1] or [Source 2] connector at
the rear panel, set the output signal waveform and parameters, turn
on or off the state display of the current signal.
Note: This function is only applicable to digital oscilloscopes with source channels.
