Chapter 5 Trigger RIGOL
MSO4000/DS4000 User’s Guide 5-33
2. Specify the trigger mode
Press Sweep to select “Auto”, “Normal” or “Single” (please refer to “Trigger
Mode”). The corresponding status light of the trigger mode currently selected in
the trigger control area (TRIGGER) at the front panel turns on.
3. Set the trigger holdoff and noise rejection
Press Setting to enter the trigger setting submenu. In this submenu:
1) Press Holdoff to adjust the holdoff time (please refer to “Trigger
Holdoff”). The range is from 100 ns to 10 s.
2) Press Noise Reject to turn the noise rejection on or off (please refer to
“
Noise Rejection”).
Note: For D0 to D15, the noise rejection is invalid.
