Chapter 1 Quick Start RIGOL

MSO4000/DS4000 User’s Guide 1-5

To Adjust the Supporting Legs

Adjust the supporting legs properly to use them as stands to tilt the oscilloscope

upwards for stable placement of the oscilloscope as well as better operation and

observation. Unfold or fold the supporting legs in the directions of the arrows as

shown in the figures below.

Figure 1-4 To Adjust the Supporting Legs

Supporting Legs
