Chapter 2 Performance Verification Test RIGOL
DS6000 Performance Verification Guide
2-1
Chapter 2 Performance Verification Test
This chapter introduces the performance verification test methods and procedures of DS6000 series
digital oscilloscope by taking DS6104 as an example. Fluke 9500B is used in this manual for the tests.
You can also use other devices that fulfill the “Specification” in Table 2-1.
Table 2-1 Test Devices Required
Test Plan
Device
Specification
Recommended Model
Plan 1
Oscilloscope
Calibrator
DC output voltage range:
1 MΩ: 1 mV to 200 V
50 MΩ: 1 mV to 200 V
The rise time of fast edge signal: ≤
150 ps
Fluke 9500B
Plan 2
Digital Multimeter
The resistance measurement
accuracy is higher than ±0.1% of
reading
RIGOL DM3058/3068
Test Cable BNC (M) to Dual-banana plug cable --
Function/Arbitrary
Waveform
Generator
Frequency accuracy: ±1 ppm
RIGOL DG4162
Dual-BNC Cable BNC (M)-BNC (M) cable --
Note:
1. Make sure that the oscilloscope passes the self-test and self-calibration is performed before
executing performance verification tests.
2. Make sure that the oscilloscope has been warmed up for at least 30 minutes before executing
any of the following tests.
3. Please reset the instrument to the factory setting before or after executing any of the following
tests.
