Rigol DS6104 Performance Verification Guide

Appendix Test Record Form RIGOL
DS6000 Performance Verification Guide
7
Time Base Accuracy Test
Channel Test Result ΔT
Calculation
Result
[1]
Limit
Pass/
Fail
CH1
±(4 ppm + 2 ppm/year × Number of years that
the instrument has been used
[2]
)
Note
[1]
: Calculation Result = Test Result ΔT/1 ms.
Note
[2]
: For the number of years that the instrument has been used, please calculate according to the date in the
verification certificate provided when the instrument leaves factory.
Zero Point Offset Test
Channel
Fast Edge Signal
Amplitude
Vertical Scale Test Result Limit Pass/Fail
CH1
1.2 Vpp 200 mV/div
≤ 0.5 div × Minimum Time
Base Scale
[1]
3 Vpp 500 mV/div
CH2
1.2 Vpp 200 mV/div
3 Vpp 500 mV/div
CH3
1.2 Vpp 200 mV/div
3 Vpp 500 mV/div
CH4
1.2 Vpp 200 mV/div
3 Vpp 500 mV/div
Note
[1]
: For different models of oscilloscopes, the minimum time base scales are different. For DS610X, the minimum
time base scale is 500 ps/div; for DS606X, the minimum time base scale is 1 ns/div.
