RIGOL Chapter 3 Programming Examples
3-4 MSO7000/DS7000 Programming Guide
4. Click Tools(T) in the Microsoft Visual Basic menu bar and select References.
In the displayed dialog box, select VISA Library, and click OK to refer to VISA Library.
Remarks:
If you cannot find VISA Library in the left section of the above dialog box, please follow the method
below to find it.
(1) Make sure that your PC has installed the NI-VISA library.
(2) Click Browse... at the right section to search visa32.dll from C:\WINDOWS\system32, as
shown in the figure below.
