Rigol DSA800 Series User Manual

Chapter 5 Specifications RIGOL
User’s Guide for DSA800/E Series
5-11
Tracking Generator (Option)
TG Output
DSA815 DSA832 DSA875 DSA832E
Frequency range
100 kHz to
1.5 GHz
100 kHz to
3.2 GHz
100 kHz to
7.5 GHz
100 kHz to
3.2 GHz
Output level range
-20 dBm to
0 dBm
-40 dBm to 0 dBm
Output level resolution 1 dB
Output flatness
relative to 50 MHz
±3 dB (nom.)
Trigger
Trigger
Trigger source free run, video, external
External trigger level 5 V TTL level
SSC-DSA (Option) (Only for DSA815)
Signal Seamless Capture (SSC)
Measurement bandwidth 1.5 MHz
