Rigol DSA800 Series User Manual

RIGOL Chapter 5 Specifications
User’s Guide for DSA800/E Series
5-12
Input /Output
Front Panel Connectors
RF input
impedance 50 Ω (nom.)
connector N female
Tracking generator
output
impedance 50 Ω (nom.)
connector N female
Internal/ External Reference
Internal reference
frequency 10 MHz
output level +3 dBm to +10 dBm, +8 dBm (typ.)
impedance 50 Ω (nom.)
connector BNC female
External reference
frequency 10 MHz ± 5 ppm
input level 0 dBm to +10 dBm
impedance 50 Ω (nom.)
connector BNC female
External Trigger Input
External trigger
input
impedance 1 kΩ (nom.)
connector BNC female
Communication Interface
USB host
connector A plug
protocol version2.0
USB device
connector B plug
protocol version2.0
LAN
LXI core
2011 device
10/100Base, RJ-45
IEC/IEEE (GPIB) bus (USB-GPIB
option)
IEEE488.2
