RIGOL Chapter 1 Quick Start
User’s Guide for DSA800/E Series
1-30
To Use the Security Lock
If necessary, use a security lock to lock the analyzer in a desired location. As shown
in the figure below, align the lock with the lock hole and plug it into the lock hole
vertically, turn the key clockwise to lock the instrument and then pull the key out.
Figure 1-15 To Use the Security Lock
Note: Please do not insert other articles into the security lock hole to avoid
damaging the instrument.
Key
Security Lock Hole
Security Lock
