RIGOL Chapter 1 Quick Start
User’s Guide for DSA800/E Series
1-4
To Prepare for Use
To Adjust the Supporting Legs
Users can unfold the supporting legs to use them as stands to tilt the instrument
upwards for easier operation and observation. Users can also fold the supporting
legs when the instrument is not in use for easier storage or shipment.
Figure 1-3 To Adjust the Supporting Legs
To unfold the supporting legs
To fold the supporting legs
