Rigol MSO1074Z Programming Guide

RIGOL Chapter 2 Command System
2-158 MSO1000Z/DS1000Z Programming Guide
:TRIGger Commands
The :TRIGger commands are used to set the trigger system of the oscilloscope.
Command List:
 :TRIGger:MODE
 :TRIGger:COUPling
 :TRIGger:STATus?
 :TRIGger:SWEep
 :TRIGger:HOLDoff
 :TRIGger:NREJect
 :TRIGger:POSition?
 :TRIGger:EDGe
 :TRIGger:PULSe
 :TRIGger:SLOPe
 :TRIGger:VIDeo
 :TRIGger:PATTern
 :TRIGger:DURATion
 :TRIGger:TIMeout
 :TRIGger:RUNT
 :TRIGger:WINDows
 :TRIGger:DELay
 :TRIGger:SHOLd
 :TRIGger:NEDGe
 :TRIGger:RS232
 :TRIGger:IIC
 :TRIGger:SPI
:TRIGger:MODE
Syntax
:TRIGger:MODE <mode>
:TRIGger:MODE?
Description
Select or query the trigger type.
Parameter
Name
Type
Range
Default
<mode>
Discrete
{EDGE|PULSe|RUNT|WIND|NEDG|SLOPe|VIDeo|
PATTern|DELay|TIMeout|DURation|SHOLd|
RS232|IIC|SPI}
EDGE
Return
Format
The query returns EDGE, PULS, RUNT, WIND, NEDG, SLOP, VID, PATT, DEL, TIM, DUR,
SHOL, RS232, IIC, or SPI.
Example
:TRIGger:MODE SLOPe /*Select slope trigger*/
:TRIGger:MODE? /*The query returns SLOP*/
