Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-193
:TRIGger:DELay:SB
Syntax
:TRIGger:DELay:SB <source>
:TRIGger:DELay:SB?
Description
Set or query the trigger source B in delay trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel2
Return
Format
The query returns CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:DELay:SB CHANnel4 /*Set the trigger source B to CH4*/
:TRIGger:DELay:SB? /*The query returns CHAN4*/
:TRIGger:DELay:SLOPB
Syntax
:TRIGger:DELay:SLOPB <slope>
:TRIGger:DELay:SLOPB?
Description
Set or query the edge type of edge B in delay trigger.
Parameter
Name
Type
Range
Default
<slope>
Discrete
{POSitive|NEGative}
POSitive
Return
Format
The query returns POS or NEG.
Example
:TRIGger:DELay:SLOPB NEGative /*Set the edge type of edge B to falling edge*/
:TRIGger:DELay:SLOPB? /*The query returns NEG*/
