Rigol MSO5000 Series User Manual

RIGOL
MSO5000 Quick Guide 3
English
Safety Symbols on the Product:
Hazardous
Voltage
Safety
Warning
Protective Earth
Terminal
Chassis Ground
Test Ground
Care and Cleaning
Care
Do not store or leave the instrument where it may be exposed to direct sunlight
for long periods of time.
Cleaning
Clean the instrument regularly according to its operating conditions.
1. Disconnect the instrument from all power sources.
2. Clean the external surfaces of the instrument with a soft cloth dampened
with mild detergent or water. When cleaning the LCD, take care to avoid
scarifying it.
CAUTION
To avoid damage to the instrument, do not expose it to caustic
liquids.
WARNING
To avoid short-circuit resulting from moisture or personal injuries,
ensure that the instrument is completely dry before connecting it
to the power supply.
Document Overview
This manual gives you a quick review about the front and rear panel of
MSO5000 series, the user interface, and the basic operation method.
Tip
For the latest version of this manual, download it from the official website
of
RIGOL
(www.rigol.com).

Rigol MSO5000 Series Specifications

General

Sample Rate	Up to 8 GSa/s
Memory Depth	Up to 200 Mpts
Bandwidth	100 MHz, 200 MHz, 350 MHz
Channels	4 analog channels
Display	9 inch capacitive multi-touch screen
Waveform Capture Rate	Up to 500, 000 wfms/s
Vertical Resolution	8-bit
Connectivity	USB Host, USB Device, LAN, HDMI
Trigger Types	Edge, Pulse, Slope, Video, Pattern, Duration, TimeOut, Runt, Window, Delay, Setup/Hold, Nth Edge
Operating System	Linux
Weight	4.6 kg
