Chapter 6 Operations and Measurements RIGOL
MSO7000/DS7000 User Guide 6-27
Math Operation Label
Press Label to enter the label setting menu.
 Press Display continuously to enable or disable the label display of the
waveform. If it is enabled, the label will be displayed at the left side of the
waveform.
 Press Library to select the preset waveform label, including ADD, SUB, MUL,
DIV, FFT, AND, OR, XOR, NOT, Intg, Diff, Sqrt, Lg, Ln, Exp, Abs, LPas, HPas, BPas,
BStop, and AX+B.
 Press Label, and the label editing interface is automatically displayed. You can
input the label manually. For details, refer to descriptions in "Channel Label".
