Chapter 19 System Utility Function Setting RIGOL
MSO7000/DS7000 User Guide 19-7
System-related
Beeper
When the beeper is enabled, you can hear the sound of the beeper when you
perform the following operations:
Press a key or a menu key on the front panel
Enable the touch screen
When a prompt message is displayed
Press Utility and then press Beeper continuously to select "ON" ( ) or "OFF" ( ).
By default, it is OFF.
Language
This oscilloscope supports menus in multiple languages. Both Chinese and English
are available for the display of the help information, prompt messages, and interface.
Press Utility Language and rotate the multi-function knob to select the
desired language; then, press down the knob to select the language. You can
also press Language continuously to select the language or enable the touch screen
to tap the desired language and select it.
System Information
Press Utility System About to view the system information of the
oscilloscope, including the manufacturer, product model, serial number, etc.
You can also view the system information of the oscilloscope in the "Help" system
menu.
Power On
You can set the system configuration to be recalled when the oscilloscope is powered
on again after power-off.
Press Utility System, and then press Power On continuously to select "Last" or
"Default". By default, it is "Last".
Last: returns to the setting of the system at last power-off.
Default: returns to the factory setting of the system.
