Rigol MSO7000 Series

Chapter 18 Store and Load RIGOL
MSO7000/DS7000 User Guide 18-21
A× B
Operation
OFF
SourceA
CH1
SourceB
CH1
Offset
0 U
Scale
500 uU
A÷B
Operation
OFF
SourceA
CH1
SourceB
CH1
Offset
0 U
Scale
500 mU
FFT
Operation
OFF
Source
CH1
Offset
0 dB
Scale
1 dB
Unit
dBm/dBV
X
Start-End
Start Freq
0 Hz
Stop Freq
10 MHz
Window Function
Hanning
Mode
Trace
View
Full
Peak Search
OFF
Peak Number
5
Threshold
5.5 dB
Excursion
1.8 dB
Table Order
Amp Order
A&&B
Operation
OFF
SourceA
CH1
SourceB
CH1
Wave Size
Medium
Thre.CH1
0 V
Thre.CH2
0 V
Thre.CH3
0 V
Thre.CH4
0 V
Sensitivity
0.3 Div
A||B
Operation
OFF
SourceA
CH1
SourceB
CH1
Wave Size
Medium
