Rigol MSO7000 Series User Manual

RIGOL Chapter 18 Store and Load
18-24 MSO7000/DS7000 User Guide
ωc1
12.5 MHz
Invert
OFF
Band Stop
Operation
OFF
Source
CH1
Offset
0 V
Scale
20 mV
ωc1
6.25 MHz
ωc1
12.5 MHz
Invert
OFF
AX+B
Operation
OFF
Source
CH1
Offset
0 V
Scale
20 mV
A
0
B
0
Invert
OFF
Logic Analyzer (LA)
[2]
Select
None
D7-D0
OFF
D15-D8
OFF
Wave Size
Medium
Arrange
D15-D0
Threshold
D7-D0
1.4 V
D15-D8
1.4 V
Label
Display
OFF
Select
D0
Label
D0
Protocol Decoding (Decode)
Bus Type
Parallel
Bus Status
OFF
Format
Hex
Label
ON
Event Table
OFF
Noise Reject
OFF
Clock
OFF
RS232
Bus Status
OFF
Baud
9.6 kbps
Tx
CH1

Rigol MSO7000 Series Specifications

General

Memory Depth	Up to 500 Mpts
Operating Temperature	0 °C to +50 °C
Channels	4 analog + 16 digital
Display	10.1 inch capacitive touchscreen
Waveform Capture Rate	Up to 600, 000 wfms/s
Vertical Resolution	8 bits
Maximum Input Voltage	400 V (DC + AC peak)
Trigger Types	Edge, Pulse, Slope, Video, Pattern, Duration, Timeout, Window, Runt, Setup/Hold, Delay, Nth Edge
Protocol Decoding	RS232/UART, I2C, SPI, CAN, LIN, FlexRay, I2S, MIL-STD-1553, ARINC429
Interfaces	USB, LAN, HDMI
