Chapter 19 System Utility Function Setting RIGOL
MSO7000/DS7000 User Guide 19-3
Connected!
Invalid IP!
IP lost!
Please wait...
IP Configuration Type
The configuration type of the IP address can be DHCP, Auto IP, or Static IP. For
different IP configuration types, the configurations for IP address and other network
parameters are different.
DHCP
Press IP Config Type, then rotate the multi-function knob or press IP Config
Type continuously to select "DHCP". Press down the knob to select it. You can
also enable the touch screen to select it. When DHPC is valid, the DHCP server in the
current network will assign the network parameters (e.g. IP address, Subnet,
Gateway, and DNS) for the oscilloscope.
Auto IP
Press IP Config Type, then rotate the multi-function knob or press IP Config
Type continuously to select "Auto IP". Press down the knob to select it. You can
also enable the touch screen to select it. In auto IP mode, the oscilloscope will get
the IP address (ranging from 169.254.0.1 to 169.254.255.254) and the subnet mask
(255.255.0.0) automatically according to the current network configuration. Only
when "DHCP" is not selected or failed to be connected, can "Auto IP" be valid.
Static IP
Press IP Config Type, then rotate the multi-function knob or press IP Config
Type continuously to select "Static IP". Press down the knob to select it. You
can also enable the touch screen to select it. When this type is valid, disable DHCP
and Auto IP manually, then "IP", "SubMask", "Gateway", and "DNS" are added to the
menu. At this time, you can self-define the network parameters (e.g. IP address) of
the oscilloscope.
1. Set IP Address
The format of the IP address is nnn.nnn.nnn.nnn. The range of the first
segment (nnn) of the address is from 0 to 255 (except 127); wherein, the valid
range is from 0 to 223. The range for the other three segments is from 0 to 255.
You are recommended to ask your network administrator for an IP address
available.
