6 Rinnai Corporation EX08C, EX11C Manual
Getting to Know your New Heating Appliance
Operating Instructions
HUMIDIFIER
REMOVE BOTTOM
COVER AND PULL OUT
TO REFILL
WARM AIR OUTLET
BOTTOM COVER
HOLD BOTH SIDES
AND PULL TOWARD
YOU
CONTROL PANEL
RATING PLATE
MODEL NUMBER,
SERIAL NUMBER,
GAS TYPE, ETC.
ENGLISH IS ON THE
RIGHT; FRENCH IS
ON THE LEFT
ROOM TEMPERATURE
SENSOR/THERMISTOR
POWER CORD
PLUG 120V AC, 60 Hz
AIR FILTER
EXHAUST PIPE
COMBUSTION AIR
INTAKE HOSE
VENT TERMINAL
COMBUSTION/AIR
EXHAUST
GAS CONNECTION
1/2” MALE NPT

Rinnai EX08C (RHFE-202FTA) Specifications

General

Brand	Rinnai
Model	EX08C (RHFE-202FTA)
Category	Furnace
Language	English
