28
2.7 TECHNICAL DATA
Infinity Model REU-A1620WD-GEN REU-A2626WD-GEN Unit
Installation External, outdoor
Flue system Direct forced exhaust -
Temperature range with water controller 37-46, 48, 50, 55, 60, 65 °C
Tempearature range with push buttons 40, 42, 50, 55, 60, 65 °C
Ignition Direct electronic ignition -
Gas consumption -
Natural Gas: Input 34.4 55.3 kW
LPG Input 34.4 (2.5kg/h) 55.3 (3.9kg/h) kW
Output 27.9 44.8 kW
Gas type and pressure
Natural gas – 2.5 kPa,
LP
gas – 2.8 kPa
-
Type Outdoor installation -
Max water flowrate 20 26 L/min
Min operation flowrate ON=1
.
5 / OFF=1.0
1
L/min
Min operating water pressure (Pmin) 10 kPa
Water pressure (@nom/max flowrate-max) - (Pw) 100/150-1000 kPa
Power supply 220-240V / 50-60Hz -
Electric consumption (remote/standby+remote)
43/2 62/2 W
Noise level 54 56 dB (A)
Weight 13.5 15.5 kg
IP protection IPx5D -
1
minimum water flowrate may vary depending on the temperature setting and the inlet water temperature.
