NeoRIB2312installationguide:12148-D04-19|19
12
13
Connect the gas supply
Refer p. 8.
Leak test
Leak test all appliance connections. When finished remove any residue with a rag, Prevent
any soapy solution coming into contact with the electrical components.
Complete the installation
Refer p. 22-28.
14
Secure engine to the enclosure
Fasten the engine to the enclosure using appropriate fasteners (not supplied), using the
three holes across the top and at least two holes on each side, refer p. 17.
15
Drill
4 x Ø 3.2 mm
holes
Assemble and fit the zero clearance box
Prepare heater engine and fit cladding
Align guide rails with the guide plate
