Installation and Programming Manual 3-31
ZONES: LABELS
Quick Key Item Default Explanation
2 8
LABELS ZONE 01
ZONE 02
ZONE 03
ZONE 04
etc.
allows for the creation and/or editing of up to 10-
characters describing each of the system’s zones
a) from this display, press [ENTER] to allow for zone
labeling
b) from this display, press [ENTER] to label Zone 1;
alternatively, you can enter another zone number
c) to assign the name of “Mary’s Bedr” to Zone 1, refer
back to the material on page 3-5 and to these steps:
press the [1] key repeatedly until an M
appears in the display;. press the DOWN-
arrow (BYP) key once to move the cursor to
the right
press the [4] key until an a appears in the
display; again, press the DOWN-arrow to
advance the cursor
press the [5] key repeatedly until an r
appears; press the DOWN-arrow to advance
the cursor
press the [5] key repeatedly until a y
appears; press the DOWN-arrow to advance
the cursor
press the [3] key repeatedly until an
apostrophe appears; press the DOWN-
arrow key
press the [5] key until an s appears
press the [6] (or [7], [8], [9], or [0]) key to
create a space and press the DOWN-arrow
to advance the cursor
begin the next word with a B, by pressing the
[1] key as required
continue this procedure and when done,
press [ENTER] to go on to the next zone;
repeat this procedure, as required, to label
other zones in the system
d) once done, press the [.] key to exit the labeling mode
INSTALLER PROG:
2)ZONES
↓
SUBJECT: ZONES
8)LABELS ¤
ZONE LABEL:
ZONE#=01 (00:01)
ZONE LABEL: 01
ZONE 01
