Installation and Programming Manual
3-52
DIALER: COMMUNICATION FORMAT
Quick Key Item Default Definition
5 3 COMMUNICATION
FORMAT
--- for each Central Station account in the installation,
choose the Communication Format, as specified by
the Central Station, for reporting customer alarms,
troubles, tests, and other events
5 3 1 For 1
st
Telephone
Number:
0000 refer to the information in the table below and enter
the 4-digit Format Code corresponding to the
communication protocol required by the
Central Station Receiver associated with the
1
st
MS Telephone Number, above.
5 3 2 For 2
nd
Telephone
Number:
0000 as above, for the receiver associated with the
2
nd
MS Telephone Number
5 3 3 For 3
rd
Telephone
Number:
0000 as above, for the receiver associated with the
3
rd
MS Telephone Number
INSTRUCTIONS:
4. Contact the Central Station monitoring the customer account(s) you are programming.
5. Obtain the Communication Format(s) being used by the digital receiver(s) processing each account.
6. For SIA and Contact I.D. formats refer to Auto Codes (on page 3-62).
7. Note the corresponding 4-digit Format Code(s) in the right-hand column.
8. Use the keypad’s (0-9) keys and, if necessary, the UP- and DOWN-arrow keys to position the cursor.
Enter the proper code accordingly for the Central Station’s Telephone Numbers, above, and press
[ENTER].
Communication Formats Format Code
Simple Pulse Protocols:
Silent Knight/ADEMCO Slow 010F
Silent Knight/ADEMCO Slow–Extended 014F
Radionics/DCI/Franklin Slow 0117
Silent Knight Fast 010E
Silent Knight Fast–Extended 014E
Sescoa/Franklin/Vertex/DCI Fast 0116
Sescoa/Franklin/Vertex/DCI–Extended 0156
Universal High Speed–Non-Extended 0112
Radionics Protocols:
Radionics, 20 PPS handshake at 1400 Hz 0202
handshake at 2300 Hz 0212
Radionics, 20 PPS–Extended handshake at 1400 Hz 0242
handshake at 2300 Hz 0252
Radionics, 40 PPS handshake at 1400 Hz 0200
handshake at 2300 Hz 0210
Radionics, 40 PPS–Extended handshake at 1400 Hz 0240
handshake at 2300 Hz 0250
Radionics, 40 PPS, with Parity handshake at 1400 Hz 0220
handshake at 2300 Hz 0230
Radionics, 40 PPS–Extended, with Parity handshake at 1400 Hz 0260
handshake at 2300 Hz 0270
Other Protocols:
Sescoa, Super Fast, with Parity 4 + 3 + Parity 0331
Sescoa, Super Fast, with Parity + ETX 4 + 3 + Parity 03B1
ADEMCO Express 4 + 2+ Parity 0520
ADEMCO Contact (Point) ID DTMF, Parity 0420
Sweden Robofon 0600
SIA Level I + II 0700
INSTALLER PROG:
5)DAILER ↓
